Rave Generation: PMC60

Reverb processor
Rave Generation: PMC60
Reverb processor emulating a classic early-80s digital reverberator. Eight authentic program banks across Room and Plate families, running at the original 24 kHz native rate with hardware-matched filtering and original Bass/Treble contour shaping. Extended workflow features including pre-delay with tempo sync, RT Extend, tilt EQ tone, and input-driven ducking.

Features

  • 8 Authentic Program BanksRoom and Plate families each with four Size variations (Small, Medium Small, Medium Large, Large). Reproduces the original program structures and processing behaviour rather than a generic plate or room algorithm. Each size loads a different ROM bank with its own topology of delays, allpasses, and output taps.
  • Native 24 kHz ClockingInternal processing follows the original operating rate (9.216 MHz crystal ÷ 384), with automatic conversion to and from your DAW session rate for period-correct character.
  • Hardware-Matched FilteringInput anti-alias, DAC reconstruction, and output low-pass stages mirror the darker bandwidth of the original unit, preserving that distinctive early-80s digital smoothness.
  • Original Bass/Treble ContourThe classic front panel switches: Bass adds low-frequency emphasis inside the feedback path for a warmer, weightier tail; Treble activates HF damping and an additional output contour filter for a naturally darkening top end.
  • RT ExtendContinuously pushes feedback beyond the factory Reverb Time presets, taking the plugin from tight hardware-accurate decays all the way out to long, atmospheric washes.
  • Pre-delay with Tempo SyncUp to 250 ms of pre-delay for separation between the dry source and the reverb bloom, or lock it to host tempo with musical divisions from 1/2 down to 1/64T including dotted and triplet values.
  • Tone Tilt EQShapes the signal entering the reverb tank from dark to bright. This is independent of the Bass and Treble contour switches, which shape feedback and output instead.
  • Input-Driven DuckingAutomatically attenuates the reverb tail when the dry input is loud, keeping mixes clean without external sidechain processing. The tail blooms back during quieter passages.
  • Insert-Friendly Utility ControlsSeparate Input, Mix, and Output Level controls make PMC60 practical on aux sends (100% wet, hardware-style) or directly on tracks.
